The Gallus Alpha represents a simple and professional entry into digital printing. Equipped with state-of-the-art technology, it combines high-quality printing results, a user-friendly interface, and Gallus' proven reliability in a compact printing system.
Whether as an addition to existing machinery or as an entry point into the digital world of label printing, the Gallus Alpha is optimized for smaller print runs and short response times, and adapts effortlessly to the demands of fast-moving markets.
The Gallus Alpha is designed as a purely digital printing solution that provides cost-effective access to digital label production. Thanks to its compact monoblock design, the machine can be set up and installed quickly, enabling a smooth start in the shortest possible time.
Available in a printing width of 340 mm, the Gallus Alpha is available with CMYK and white, as well as optional orange and violet for color space expansion. It scores with high-resolution printing results at 1200 × 1200 dpi and a printing speed of 65 m/min.
With intuitive operation, high flexibility, and compact design, the Gallus Alpha offers everything that modern production environments need today—especially where time, space, and personnel resources are limited.
| 340 | |
| Machine speed, mechanical, max. | 65 m/min. 213 ft/min. |
| Maximum print width | 340 mm 1:39 p.m. |
| Productivity | 1326 m²/h (14,270 ft²/h) |
| Maximum track width | 345 mm 13:58 in |
| Splice inspection | automatically |
| Teknek rail cleaning | Front side |
| Corona | Front side |
| Antistatic system | Passive |
| 340 mm | |
| Printing method | UV Piezo DoD - Inkjet (Epson Printhead) |
| Print resolution | 1200 x 1200 dpi native print resolution with 3.5 pL drop size, optical resolution 2400 x 2400 dpi |
| Ink | Heidelberg Saphira UA01 |
| Colors | CMYK (cyan, magenta, yellow, black), optional orange, violet |
| White (optional) | 85% opacity at 65 m/min |
| Pinning | Single-color pinning / UV-LED air-cooled |
| UV curing | LED curing |
| Automatic cleaning system | contactless |
| Vision System | Optional automatic visualization |
| Digital Print Control | Optional automatic detection of missing nozzles and control of density differences |
| Substrate qualification | Optional automatic inline qualification (100% system supported) |
| Industrial Variable Data Printing (iVDP) | Industrial Variable Data (iVDP) included, Full VDP optional |
| Insetting | Yes |
| 340 / 430mm | |
| Digital Front End (DFE) | Server/client architecture |
| Server | Hardware or virtualized |
| Ink consumption | Preliminary calculation |
| 340 mm | |
| Monofilm | yes |
| Paper | yes |
| Substrate materials | yes |
| 340 mm | |
| Voltage | 380-415 V / 50 Hz [USA, Canada, MX optional: 480 V / 60 Hz] |
| Power connection | 4c+w: 67 kW (about 100 A) 6c+w: 74 kW (approximately 107 A) |
| Compressed air | 6 bar, oil- and water-free |
| Exhaust air | 200 m³/h (DPU) 350 m³/h (corona treatment) |
| Compliance | CE (UL upon request) |
| Network connections | Secomea for remote support |
| Cooling system | Air for pinning systems, water for UV LED lamp heads, electronics, and web (cooling roller) |
| Room temperature | 22–26 °C |
| Humidity (relative) | 45-60% |
| Air pressure (location) | 700 - 1060 mbar (10.5 - 15.37 PSI) |
| 340mm | |
| Length | 5420 mm (214 in) |
| Width | 2035 mm (80 in) |
| Height | 2130 mm (84 in), with DPU open 2942 mm (116 in) |
| 340 | |
| Infeed | 1500 mm (59 in) |
| Delivery | 1500 mm (59 in) |
| Front | 1500 mm (59 in) |
| Back | 1500 mm (59 in) |
| Evenness | ± 1 cm over a length of 10 m |
| Floor capacity | 1600 kg/m² (2,2757 psi) |
| All technical data, descriptions, and illustrations are subject to change and are not binding. |
